1. Introduction

Thank you for choosing the Audio Array AI-04 2x2 Audio Interface. This high-quality device is designed to provide professional-grade audio recording and playback capabilities with its premium mic pre-amps and 48V phantom power support. Whether you're a musician, podcaster, or audio engineer, the AI-04 will meet your needs with its versatile connectivity and high-fidelity sound.

2. Package Inclusions

  • 1 x Audio Array AI-04 Audio Interface
  • 1 x USB 2.0 B-Male to A-Male Cable
  • 1 x USB 2.0 A-Male to Type-C Adapter
  • 1 x Type-C to USB A-Male Cable
  • 1 x User Manual

If you have any questions or need assistance, please contact our support team. The product is covered under a 3-year warranty.

3. Features and Technical Specifications

Professional Audio Interface:

  • 24-bit/192kHz resolution
  • 2 in/2 out configuration
  • Low latency

Connectivity:

  • 2 combo XLR/MIC/LINE inputs with 48V phantom power
  • 2 independent TRS/TS stereo jacks
  • 1/4" TRS/TS inputs

Controls:

  • USB interface with high-quality preamps
  • Separate volume control
  • Signal & overload indicators
  • Fast fade buttons

Audio Quality:

  • High-performance converters
  • Low-noise balanced outputs
  • High-fidelity private listening with headphones

Compatibility:

  • Plug-and-play USB interface
  • No drivers needed
  • Compatible with Mac OS and Windows XP+
  • Works with popular recording software (Pro Tools, Ableton, Cubase, etc.)
  • Portable design for on-the-go production

4. Setup Instructions

  1. Unbox and Inspect: Remove all items from the package and ensure everything is present.
  2. Connect to Computer:
    • Use the USB 2.0 B-Male to A-Male Cable to connect the AI-04 to your computer.
    • Alternatively, use the provided USB 2.0 A-Male to Type-C Adapter or Type-C to USB A-Male Cable if needed.
  3. Install Software:
    • The AI-04 is plug-and-play, so no drivers are required.
    • Ensure your recording software is installed (Pro Tools, Ableton, Cubase, etc.).
  4. Power Up:
    • Connect your microphones or instruments to the XLR/MIC/LINE inputs.
    • Use the 48V phantom power switch if using condenser microphones.
    • Connect speakers or headphones to the TRS/TS stereo jacks.
  5. Configuration:
    • Open your recording software and select the AI-04 as your input/output device.
    • Adjust the input levels and monitor signals using the interface controls.

5. Usage Guide

Recording:

  • Ensure your microphone or instrument is properly connected.
  • Adjust the gain levels using the volume controls on the interface.
  • Monitor the signal and overload indicators to prevent clipping.
  • Start your recording session in your chosen software.

Playback:

  • Connect your headphones or speakers to the output jacks.
  • Adjust the playback volume to a comfortable level.
  • Use the fast fade buttons for quick adjustments during playback.

6. Troubleshooting

No Sound:

  • Check all cable connections.
  • Ensure the correct input/output device is selected in your software.
  • Verify the volume levels are not muted or too low.

Distorted Audio:

  • Reduce the gain levels on the interface.
  • Check for clipping indicators and adjust accordingly.
  • Ensure the correct sample rate and bit depth are set in your software.

Device Not Recognized:

  • Reconnect the USB cable.
  • Try a different USB port on your computer.
  • Restart your computer and the AI-04 interface.

Phantom Power Issues:

  • Ensure the 48V switch is turned on for condenser microphones.
  • Verify the microphone requires phantom power.

7. Warranty and Support

The Audio Array AI-04 is covered under a 3-year warranty. For any questions or support, please contact our customer service team.


Thank you for choosing the Audio Array AI-04. We hope this guide helps you get the most out of your audio interface. Enjoy your high-fidelity recordings!
